工业设备接插板

PCB ： FR4 508 X 190.5 x 2.8 mm                                                                                                                       难点：                                                                                                                                                                 1. 板子特别大 ，SMT贴片困难 ；                                                                                                                                             2. 用了10个 AMP:215334-4 连接器，生产过炉非常难 。

PCBA for communication

Base Material:ALU,FR4,CEM3
Copper Thickness:0.3-3oz
Board Thickness:0.3-6mm
Min. Hole Size:0.2mm
Min. Line Width:3mil
Min. Line Spacing:3mil
Surface Finishing:HASL, OSP, Immersion Gold/Au, Immersion silver, etc.

PCBA for Robot machine

Base Material:FR4, Copper Thickness:0.3-3oz Board Thickness:0.3-6mm Min. Hole Size:0.2mm Min. Line Width:3mil Min. Line Spacing:3mil Surface Finishing:HASL, OSP, Immersion Gold/Au, Immersion silver, etc. PCB:Customized PCB Tolerance of finished thickness:±5% Hole tolerance:PTH:±0.075,NTPH:±0.05 Solder mask:green/black/white/red/blue/yellow Max board size:1200mm*600mm profiling punching:Routing, V-CUT, Beveling Layer Count:1-10 Wrap and twist:5%

FPCA

FPCA 64.0 x 170.0 x 0.2 mm，2 layer,1 OZ,Immersion Gold1 596pcs WS2812C-2020 LED + 596pcs 0210 capacitor
